Stmicroelectronics Input Devices Driver

Posted on by

  • Root:/ evtest /dev/input/event1 Input driver version is 1.0.0 Input device ID: bus 0x18 vendor 0x0 product 0x159 version 0x0 Input device name: 'ADXL34x accelerometer' Supported events: Event type 0 (Reset) Event code 0 (Reset) Event code 1 (Key) Event code 3 (Absolute) Event type 1 (Key) Event code 330 (Touch) Event type 3 (Absolute) Event.
  • Then libgpiod is used to set and clear the encoder input pins, to 'emulate' an external quadrature encoder device. Step-by-step example: Externally connect and initialise GPIO pins to TIM or LPTIM encoder input pins, to 'emulate' an external quadrature encoder.
  • STMicroelectronics Pioneers Smaller and Faster Chargers and Power Supplies with World’s First Driver and GaN Device. World’s first solution to integrate Si driver and GaN power transistors in.

STMicroelectronics Motor Drivers are a wide range of motor drivers covering the requirements of brushed DC motors, stepper motors, and brushless DC motors. The drivers are offered in an extensive range of voltage and current ratings. STSPIN motor drivers embed all the functions needed to drive motors efficiently.

Install Drivers for STMicroelectronicsDiscovery Boards

TouchpadInput

Before you start working on Support Package for STMicroelectronics® Discovery™ boards, you must first configure your computer to detect the STMicroelectronics Discovery board.

Input

To detect the Support Package for STMicroelectronics Discovery board:

WhatStmicroelectronics input devices driver touchpad

Stmicroelectronics Driver Download

  1. Connect the STMicroelectronics Discovery boardto a USB port of your computer.

    When you connect, the STMicroelectronics Discovery board detection light starts blinking and then stops when your computer detects the Discovery board.

    The STM32F4–Discovery board is as shown.

    The STM32F746G-Discovery board is as shown.

    The STM32F769I-Discovery board is as shown.

  2. On the STSW-LINK009 page, in the Get Software section, click . Download the zip file on your computer, and extract the driver installation executable from the zip file. This step requires you to have the login credentials of the STSW-LINK009 web page.

    To install the driver software, you can use either of the following methods:

    • Double-click the extracted executable dpinst_amd64.exe, and follow the installation steps.

    • Right-click Device Manager > Other Devices > ST-Link Debug and then click Update Driver Software. Select the option Browse my computer for driver software. In the Browse window, specify the path of the folder that you have unzipped, for example, C:en.stsw-link009.

  3. After the driver is detected, you see the STMicroelectronicsSTLink dongle under the Universal Serial Bus devices asshown.
